EXHAUST SYSTEM Spare Parts — Genuine OEM

1

ASSEMBLY EXHAUST PIPE A

JY591275 · MY 2017, 2018, 2019 · ₹1,497

JY5912752017, 2018, 2019₹1,497

2

ASSEMBLY PRE MUFFLER

JY591299 · MY 2017, 2018, 2019 · ₹4,207

JY5912992017, 2018, 2019₹4,207

3

ASSEMBLY PREMUFFLER WITH CHILD PARTS

52JP0670 · MY 2020, 2021, 2022, 2023 · ₹4,293

52JP06702020, 2021, 2022, 2023₹4,293

4

MUFFLER ASSEMBLY

JP591195 · MY 2023, 2024 · ₹4,898

JP5911952023, 2024₹4,898

5

PIPE ASSEMBLY A

JP591132 · MY 2020, 2021, 2022, 2023 · ₹32,279

JP5911322020, 2021, 2022, 2023₹32,279

6

PIPE ASSEMBLY A

JP591293 · MY 2022, 2023 · ₹30,900

JP5912932022, 2023₹30,900

7

PIPE ASSEMBLY A

JP591010 · MY 2020, 2021 · ₹14,256

JP5910102020, 2021₹14,256

8

SILENCER SUB ASSLY

JY591250 · MY 2015, 2016 · ₹18,020

JY5912502015, 2016₹18,020

9

MUFFLER SUB ASSEMBLY

JY591009 · MY 2017, 2018, 2019

JY5910092017, 2018, 2019—

10

PIPE A EXHAUST ASSLY

JY591032 · MY 2015, 2016 · ₹1,269

JY5910322015, 2016₹1,269

11

PIPE ASSEMBLY A

JP591476 · MY 2023, 2024 · ₹11,145

JP5914762023, 2024₹11,145

12

PIPE ASSEMBLY A

JP591392 · MY 2023 · ₹12,989

JP5913922023₹12,989

13

DAMPER SILENCER MOUNTING LOWER

JG591100 · MY 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 · ₹11

JG5911002015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023₹11

14

GASKET EXHAUST

JG591070 · MY 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023 · ₹64

JG5910702015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023₹64

15

PIPE ASSEMBLY A (For OBD2B)

JP591484 · MY 2023 · ₹12,153

JP5914842023₹12,153

16

PIPE ASSEMBLY A (For OBD2B)

JP591480 · MY 2023, 2024 · ₹11,246

JP5914802023, 2024₹11,246

17

SHIELD ASSEMBLY MUFFLER

JY591404 · MY 2022, 2023 · ₹693

JY5914042022, 2023₹693

18

SHIELD ASSEMBLY MUFFLER

JG591136 · MY 2020, 2021 · ₹462

JG5911362020, 2021₹462

19

BOLT FLANGED-M8X1.25XL 43

LAD00065 · MY 2015, 2016, 2020, 2021, 2022, 2023 · ₹19.2

LAD000652015, 2016, 2020, 2021, 2022, 2023₹19.2

20

BOLT FLANGED-M8X1.25XL50

LAD00236 · MY 2020, 2021, 2022, 2023 · ₹17.9

LAD002362020, 2021, 2022, 2023₹17.9

21

CLAMP

JP591363 · MY 2023, 2024 · ₹179

JP5913632023, 2024₹179

22

O2 SENSOR

JG511010 · MY 2015, 2016, 2017, 2018, 2019 · ₹3,000

JG5110102015, 2016, 2017, 2018, 2019₹3,000

23

BAND CLIP

JY591015 · MY 2015, 2016 · ₹144

JY5910152015, 2016₹144

24

COLLAR

JY591245 · MY 2017, 2018, 2019, 2020, 2021, 2022, 2023 · ₹31.4

JY5912452017, 2018, 2019, 2020, 2021, 2022, 2023₹31.4

25

PIPE SILENCER MOUNTING

JG591055 · MY 2015, 2016, 2017, 2018, 2019 · ₹49

JG5910552015, 2016, 2017, 2018, 2019₹49

26

SHIELD

JP591417 · MY 2023, 2024 · ₹190

JP5914172023, 2024₹190

27

SHIELD

JP591414 · MY 2023 · ₹319

JP5914142023₹319

28

WASHER PLAIN

LDA00009 · MY 2020, 2021, 2022, 2023 · ₹3.64

LDA000092020, 2021, 2022, 2023₹3.64

29

BOLT-FLANGE-KAD ST-D DIA-08 L-35

KADD0835 · MY 2020, 2021, 2022, 2023 · ₹7.8

KADD08352020, 2021, 2022, 2023₹7.8

30

DAMPER MUFFLER

JY591246 · MY 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 · ₹12

JY5912462017, 2018, 2019, 2020, 2021, 2022, 2023, 2024₹12

31

DAMPER SILENCER MOUNTING LOWER

JL591165 · MY 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 · ₹13.6

JL5911652015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024₹13.6

32

GASKET EXHAUST

TA591206 · MY 2023, 2024 · ₹87

TA5912062023, 2024₹87

33

GASKET MUFFLER PIPE A

JY591014 · MY 2015, 2016 · ₹76

JY5910142015, 2016₹76

34

SHIELD

JP591364 · MY 2023 · ₹277

JP5913642023₹277

35

BRACKET MUFFLER

JY591226 · MY 2020, 2021, 2022, 2023 · ₹211

JY5912262020, 2021, 2022, 2023₹211

36

SHIELD MUFFLER

JP591240 · MY 2023, 2024 · ₹149

JP5912402023, 2024₹149

37

SLEEVE TOP

JL591156 · MY 2015, 2016, 2017, 2018, 2019, 2023, 2024 · ₹12.6

JL5911562015, 2016, 2017, 2018, 2019, 2023, 2024₹12.6

38

ASSEMBLY SHIELD MUFFLER

JY591297 · MY 2017, 2018, 2019, 2020, 2021 · ₹396

JY5912972017, 2018, 2019, 2020, 2021₹396

39

ASSEMBLY SHIELD MUFFLER

- · MY 2022, 2023

-2022, 2023—

40

BOLT FLANGED M6X1

LAD00355 · MY 2023, 2024 · ₹5.7

LAD003552023, 2024₹5.7

41

BOLT SOCKET-M8 X 1.25 X L30 X SS

LAC00127 · MY 2017, 2018, 2019 · ₹15.1

LAC001272017, 2018, 2019₹15.1

42

CLAMP

JG591143 · MY 2020, 2021, 2022, 2023 · ₹182

JG5911432020, 2021, 2022, 2023₹182

43

BOLT FLANGED M6X1

JG113837 · MY 2020, 2021, 2022, 2023, 2024 · ₹3.8

JG1138372020, 2021, 2022, 2023, 2024₹3.8

44

BOLT FLANGED M8*1.25*110L

LAD00061 · MY 2015, 2016, 2017 · ₹21.8

LAD000612015, 2016, 2017₹21.8

45

BOLT SOCKET-M8 X 1.25 X L40X SS

LAC00089 · MY 2017, 2018, 2019 · ₹15.3

LAC000892017, 2018, 2019₹15.3

46

GROMMET SHIELD MUFFLER

JY591303 · MY 2017, 2018, 2019, 2020, 2021, 2022, 2023 · ₹6.7

JY5913032017, 2018, 2019, 2020, 2021, 2022, 2023₹6.7

47

BOLT M6

KADQ0625 · MY 2015, 2016, 2017, 2018, 2019 · ₹5

KADQ06252015, 2016, 2017, 2018, 2019₹5

48

SCREW BUTTON HD- M6X1XL10XPRECOAT

LBU00045 · MY 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024 · ₹4.64

LBU000452017, 2018, 2019, 2020, 2021, 2022, 2023, 2024₹4.64

49

CLIP NUT M6

JG591088 · MY 2015, 2016 · ₹6.5

JG5910882015, 2016₹6.5

50

GASKET PIPE B

JY591278 · MY 2017, 2018, 2019 · ₹66

JY5912782017, 2018, 2019₹66

51

SENSOR OXYGEN

JP591114 · MY 2020, 2021, 2022, 2023 · ₹2,437

JP5911142020, 2021, 2022, 2023₹2,437

52

CLAMP DIA 54

JY591279 · MY 2017, 2018, 2019 · ₹148

JY5912792017, 2018, 2019₹148

53

SHIELD MUFFLER

JP591341 · MY 2023 · ₹985

JP5913412023₹985

54

SHIELD MUFFLER

JU591205 · MY 2024 · ₹733

JU5912052024₹733

55

ASSEMBLY CAT

JY591280 · MY 2017, 2018, 2019 · ₹16,617

JY5912802017, 2018, 2019₹16,617

56

BOLT FLANGED M8X1.25

KADF0835 · MY 2023, 2024 · ₹10

KADF08352023, 2024₹10

57

NUT HEX FLANGED- M8X1.25XHT.8XBRT

LCG00024 · MY 2020, 2021, 2022, 2023

LCG000242020, 2021, 2022, 2023—

58

Collar

JP591393 · MY 2023, 2024 · ₹30.3

JP5913932023, 2024₹30.3

59

GASKET PIPE C

JY591286 · MY 2017, 2018, 2019 · ₹71

JY5912862017, 2018, 2019₹71

60

CLAMP DIA 60

JY591287 · MY 2017, 2018, 2019 · ₹139

JY5912872017, 2018, 2019₹139

61

ASSEMBLY MUFFLER

JY591350 · MY 2018, 2019 · ₹4,693

JY5913502018, 2019₹4,693

62

NUT HEX FLANGE- M8X1.25XCL8XDACRO

KCGN0808 · MY 2020, 2021, 2022, 2023 · ₹4.7

KCGN08082020, 2021, 2022, 2023₹4.7

63

SHIELD

JP591367 · MY 2023, 2024 · ₹58

JP5913672023, 2024₹58

64

CLIP NUT

JG113404 · MY 2020, 2021, 2022, 2023 · ₹6.5

JG1134042020, 2021, 2022, 2023₹6.5

65

SENSOR OXYGEN

JP591412 · MY 2023, 2024 · ₹2,836

JP5914122023, 2024₹2,836

66

BOLT FLANGED-M8X1.25XL 105XBRT

LAD00075 · MY 2020, 2021, 2022, 2023 · ₹18.6

LAD000752020, 2021, 2022, 2023₹18.6

67

NUT HEX FLANGED M8*1.25

LCG00006 · MY 2023, 2024 · ₹5.8

LCG000062023, 2024₹5.8

68

GASKET EXHAUST

JF591242 · MY 2023, 2024 · ₹114

JF5912422023, 2024₹114

69

MUFFLER ASSEMBLY SECONDARY

JG591120 · MY 2020, 2021 · ₹7,948

JG5911202020, 2021₹7,948

70

MUFFLER ASSEMBLY SECONDARY

JY591431 · MY 2022, 2023 · ₹6,874

JY5914312022, 2023₹6,874

71

SENSOR OXYGEN (For OBD2B)

JP591407 · MY 2023, 2024 · ₹2,612

JP5914072023, 2024₹2,612

72

ADHESIVE -LOCTITE C5-A COPR BASE

LZC00011 · MY 2020, 2021, 2022, 2023

LZC000112020, 2021, 2022, 2023—

73

CLAMP (For OBD2B)

JP402355 · MY 2023 · ₹7.8

JP4023552023₹7.8

74

GASKET MUFFLER PRIMARY

JP591042 · MY 2020, 2021, 2022, 2023 · ₹112

JP5910422020, 2021, 2022, 2023₹112

75

GASKET MUFFLER SECONDARY

JP591033 · MY 2020, 2021, 2022, 2023 · ₹76

JP5910332020, 2021, 2022, 2023₹76

76

MUFFLER ASSEMBLY SECONDARY

JP591028 · MY 2020, 2021, 2022, 2023 · ₹4,628

JP5910282020, 2021, 2022, 2023₹4,628

77

SHIELD (For OBD2B)

JP591442 · MY 2023 · ₹202

JP5914422023₹202

78

PROTECTOR MUFFLER INNER REAR

JP591044 · MY 2020, 2021, 2022, 2023 · ₹330

JP5910442020, 2021, 2022, 2023₹330

79

BOLT FLANGED

KADD0612 · MY 2020, 2021, 2022, 2023 · ₹2.9

KADD06122020, 2021, 2022, 2023₹2.9

80

BUSH

JH111172 · MY 2020, 2021, 2022, 2023

JH1111722020, 2021, 2022, 2023—

81

PROTECTOR ASSEMBLY MUFFLER OUTER

JP591045 · MY 2020, 2021, 2022, 2023 · ₹1,053

JP5910452020, 2021, 2022, 2023₹1,053

82

PROTECTOR MUFFLER INNER MIDDLE

JP591043 · MY 2020, 2021, 2022, 2023 · ₹171

JP5910432020, 2021, 2022, 2023₹171

83

PROTECTOR MUFFLER INNER FRONT

JP591082 · MY 2020, 2021, 2022, 2023 · ₹430

JP5910822020, 2021, 2022, 2023₹430

84

CLAMP

JP591012 · MY 2020, 2021, 2022, 2023 · ₹187

JP5910122020, 2021, 2022, 2023₹187

85

CLAMP

JP591013 · MY 2020, 2021, 2022, 2023 · ₹141

JP5910132020, 2021, 2022, 2023₹141
